Installing a WiFi Mini-Controller for LED strips

Connection with power adapter

Step 1

Connect the power adapter to the led strips. When connecting more than one led strips, please ensure that the wattage of the power adaptor is higher than the sum of the two strips.

Installing a Mini-Controller - Step 1

Step 2

The mini-controller has two output channels, i.e. Two positives and two negatives. For correct operation, one positive and one negative must be connected to the jack connector, in accordance with the polarity.

Installing a Mini-Controller - Step 2

Finished installation

The wiring diagram for two led strips can be seen in full. The controller is ready to operate with either one or two strips.

Installing a Mini-Controller - Finished installation

Power supply connection

When connecting a power supply unit, the jack connector must be connected to the output of the power supply unit, in accordance with the polarity of the power supply unit.

Installing a Mini-Controller - Step 4
