Voltage Range 220-240V AC
Max Wattage 300 W
IP Rating IP20
Dimensions 102 mm x 102 mm x 60 mm

1 / 7

Voltage Range
220-240V AC
Max Wattage
300 W
IP Rating
IP20
Dimensions
102 mm x 102 mm x 60 mm
Width
102 mm
Height
102 mm
Fitting Material
PC

Colour : White

In Stock, delivery in 15-20 days

Before £21.89

-45% (You save £9.90)

£11.99

VAT included

In Stock, delivery in 15-20 days

Includes IR remote control

Are you a lighting professional or a company?

Great discounts off PVP
Extended Warranty
Exclusive Services

See alternatives

Dimensions

Height102 mm
Depth60 mm
Dimensions102 mm x 102 mm x 60 mm
Width102 mm

Downloads

Technical Data Sheet PDF

Certificates and Stamps

Technical Specifications

Technical Information
- Temperature range in which the product can operate optimally, ensuring its performance without overheating or damage.
  Ambient Working Temperature-20 °C~+50 °C
- Quality, safety and compliance certifications that the product has obtained, such as CE, RoHS or UL, which guarantees that it meets industry standards and current regulations.
  CertificatesRoHS, CE, UKCA
- Specification of the color of the product or its light (in the case of products such as lamps or light bulbs), which may affect the aesthetics and functionality of its use.
  ColourWhite
- Defines the sensitivity area of a sensor in degrees. A larger angle will detect movements over a wider range, useful in security systems or automatic lights.
  Detection Range360 °
- Component that identifies changes in the environment, such as movement, light or sound, activating an automatic response, ideal for security or intelligent lighting systems.
  DetectorPIR
- Composition of the product or its components, such as aluminum, steel, plastic or glass. The material influences the durability, design and thermal properties of the product.
  Fitting MaterialPC
- Range of cycles per second at which the product operates, measured in hertz (Hz). A standard value ensures compatibility with local electrical networks.
  Frequency50-60 Hz
- Information on how the product should be placed or mounted, such as instructions on whether it requires professional installation or is easy to do by the end user.
  InstallationSurface
- Level of protection against the entry of solids and liquids, according to international regulations. The two numbers indicate protection against dust (first number) and against water (second number).
  IP RatingIP20
- Specification that describes the purpose or application of the product, such as lighting, air conditioning, or security, among others.
  LocationIndoor
- The maximum amount of power that the product can safely consume, indicated in watts. It is important to ensure proper installation and avoid overloading.
  Max Wattage300 W
- Voltage level necessary for the product to function correctly. Ensures its compatibility with the electrical network or with specific power systems.
  Voltage Range220-240V AC
Product Data
- Period during which the customer has the right to have their product repaired or replaced in the event of manufacturing defects or malfunctions under normal conditions of use. For more information, consult our After-sales page.
  Warranty3 years

Description

360º PIR Motion Sensor for Corridors with Remote Control in white for indoor use.

It has an infrared sensor with a detection angle of 360° and a range of 20m, so you will be able to capture any movement within its range from anywhere.

It is surface mounted and is recommended to be installed at a height between 2.5-10m.

Minimum ON time: 10 seconds.

Maximum ON time: 30 minutes.

This sensor is capable of withstanding a LED load of up to 1000 W, and in the case of incandescent, 2000 W.

You can select the threshold from which you want the sensor to start detecting, 5, 10, 10, 20, 30, 30, 50, 100, 200 LUX or 24h detection regardless of whether there is ambient light or not.
