Power 40 W
Tension 220-240V AC
Luminosity 6000 lm
Number of LEDs 24
Power
40 W
Tension
220-240V AC
Luminosity
6000 lm
Number of LEDs
24
Power Factor
0.95
IP protection
IP66
Battery operated
No
Width
766 mm
Height
440 mm
IK protection
IK09
Luminous Efficiency
150 lm/W
Material
Glass, Aluminium
40W LED Street Light LUMILEDS PHILIPS Xitanium Villa
Ref. Ledkia: 70509
Colour Temperature :
Neutral White 4000K
Optic :
Asymmetrical 140ºx60º
In stock, estimated delivery 9 to 10 days
£343.99
20% VAT included
In stock, estimated delivery 9 to 10 days
Are you a lighting professional or a company?
- Great discounts on RRP
- Extended warranty
- Exclusive services
Buy now, pay later
Credit payment30 Day Return
You can renounce to this product during the first 30 calendar days from receipt, provided that the product remains in perfect condition for use.
Custom-made products and cut-to-size strips are excluded.
Full conditions here: After-sales service.
24h Free Delivery
If you place your order today before 16:30h, delivery within 24/48h (working days).
Shipping is free on purchases over £ 49.99 (incl. VAT).
Full conditions here: Delivery methods.
100% secure payments
At Ledkia we strive to protect your security and privacy. We use payment methods that guarantee your security. Both your personal and bank details are protected with all the security measures established in the current legislation.
More information: Payment methods.
Up to 5 year warranty
Our warranty service of up to 5 years guarantees the replacement, repair or refund of defective products.
You will find the exact product warranty in the technical details.
Full conditions here: After-sales service.
Dimensions
- Height440 mm
- Width766 mm
- Weight10.2 kg
Downloads
Technical Data Sheet PDF
Certificates and Stamps
Energy Efficiency
Regulation 2023Technical Specifications
- Light colourNeutral White
- Colour Temperature4000K
- Energy efficiency 2023 (EU-2019/2015)D
- OpticAsymmetrical 140ºx60º
- Available ComponentsYes
- Replaceable driverYes
- Replaceable light sourceYes
- Power40 W
- Power Factor0.95
- Tension220-240V AC
- Nominal Voltage100-240V AC
- Overvoltage Protection6 kV
- Frequency50-60 Hz
- electrical insulation classI
- DimmableNo
- Light SourceLUMILEDS SMD5050
- Number of LEDs24
- Luminosity6000 lm
- Luminous Efficiency150 lm/W
- LED performance160 lm/W
- UseOutdoor
- IP protectionIP66
- IK protectionIK09
- ULORLess than 0.1%
- MaterialGlass, Aluminium
- ColourBlack
- Height440 mm
- Width766 mm
- Weight10.2 kg
- Ambient Working Temperature-20 °C~+45 °C
- Battery operatedNo
- WiFiNo
- Lifespan100.000 hours
- CertificatesRoHS, CE, ENEC
- Warranty5 years
- Includes sensorNo
- Contains batteryNo
- Driver brandPHILIPS Xitanium
Description
The 40W LED Street Light LUMILEDS PHILIPS Xitanium Villa is one of the latest generation of luminaires, offering instantaneous lighting thanks to its LED technology, as well as high power. It is the ideal replacement for the old discharge lamps, improving the quality of light and significantly reducing its energy consumption.
Characteristics of the 40W LED Street Light LUMILEDS PHILIPS Xitanium Villa
Incorporated with LUXEON 5050 2D light source. The light source is protected with tempered glass with an IP66 protection factor that makes it weatherproof. Lumileds technology guarantees high light output with extreme durability. Lumileds is a company that develops, manufactures and distributes lighting and holds more than 200 patents related to LED technology.
The body of the luminaire has been manufactured using the injection method to guarantee the optimum quality of the heatsink, in high quality aluminium. It has an interior hinge that improves its aesthetics without losing its versatility. An anti-corrosion treatment has been applied to it, both chemical and mechanical, which is resistant to UV rays and which further improves its aesthetic durability. In addition, for greater safety, the luminaire has a surge protector.
Characteristics of the XITANIUM Driver
A LED driver converts the alternating current from the mains supply into direct current, which can be used to illuminate the LED chips. The Xitanium Driver that it incorporates is from the prestigious company PHILIPS, one of the most innovative and prestigious brands in the lighting industry. This driver has been specially designed for Public Lighting. This range of drivers offers a unique reliability and flexibility, providing a high performance and optimum efficiency of LEDs. The entire range of Xitanium drivers incorporates an IP65 housing that protects against humidity, vibrations and temperature, guaranteeing maximum durability. In addition, it includes both over-temperature and surge protection.
This driver features several control functions. One of them being the 5 step dimming phase. This type of technology is called Fixed Time Based Dimming (FTBD). The 5 dimming phases are assigned a power capacity and a time duration. This way, when there is no traffic, the amount of light emitted by the luminaire is reduced, adapting intelligently to the different night scenarios and considerably reducing electricity consumption.
The other regulating function of the luminaire is carried out by means of 1-10V dimming, where the voltage of an alternate circuit is modified to regulate the intensity of light in the luminaire.
Reducing energy consumption means significant savings for any urban centre. Enjoy the best street lighting with the different options of our Aventino Luminaire at your online shop Ledkia.
* The colour code of the luminaire is RAL 90011
* To install the LUMILEDS Villa Street Light on some columns it is required to use the 'LED Villa Column Fixing Support' (see accessories).
