Voltage Range 24V DC, 12V DC
Max Wattage 120 W
Type Of Dimming DALI
IP Rating IP20

1 / 2

Voltage Range
24V DC, 12V DC
Max Wattage
120 W
Type Of Dimming
DALI
IP Rating
IP20
Dimensions
120 mm x 87 mm x 55 mm
Width
87 mm
Height
120 mm
Fitting Material
PC
Dimmable
Yes

Colour : White

Pre-Order, estimated delivery from 10 weeks

£35.69

VAT included

Pre-Order, estimated delivery from 10 weeks

Are you a lighting professional or a company?

Great discounts off PVP
Extended Warranty
Exclusive Services

See alternatives

Dimensions

Height120 mm
Depth55 mm
Dimensions120 mm x 87 mm x 55 mm
Width87 mm

Downloads

Technical Data Sheet PDF

Certificates and Stamps

Technical Specifications

Technical Information
- Temperature range in which the product can operate optimally, ensuring its performance without overheating or damage.
  Ambient Working Temperature-20 °C~+50 °C
- Quality, safety and compliance certifications that the product has obtained, such as CE, RoHS or UL, which guarantees that it meets industry standards and current regulations.
  CertificatesRoHS, CE
- Specification of the color of the product or its light (in the case of products such as lamps or light bulbs), which may affect the aesthetics and functionality of its use.
  ColourWhite
- It indicates that the product allows parameters such as light intensity, speed or color temperature to be adjusted, providing greater flexibility and customization.
  DimmableYes
- Composition of the product or its components, such as aluminum, steel, plastic or glass. The material influences the durability, design and thermal properties of the product.
  Fitting MaterialPC
- Level of protection against the entry of solids and liquids, according to international regulations. The two numbers indicate protection against dust (first number) and against water (second number).
  IP RatingIP20
- Specification that describes the purpose or application of the product, such as lighting, air conditioning, or security, among others.
  LocationIndoor
- The maximum amount of power that the product can safely consume, indicated in watts. It is important to ensure proper installation and avoid overloading.
  Max Wattage120 W
- Indicates the maximum amount of current that the product can safely supply to connected devices, ensuring efficient performance.
  Maximum Output Current5 A
- Voltage level necessary for the product to function correctly. Ensures its compatibility with the electrical network or with specific power systems.
  Voltage Range24V DC, 12V DC
Product Data
- Period during which the customer has the right to have their product repaired or replaced in the event of manufacturing defects or malfunctions under normal conditions of use. For more information, consult our After-sales page.
  Warranty5 years
Product Information
- System used to control product characteristics, such as intensity regulation, color temperature or speed, adjusting its performance according to the user's needs.
  Type Of DimmingDALI

Description

The 4-Channel DALI LED Strip Dimmer for DIN Rail is a control device for Monochrome LED Strips using the Digital DALI protocol. Each channel of this dimmer provides a constant current of 5 amps. In addition, this dimmer allows you to select between one or up to four different DALI addresses, making it easy to customise the lighting control in your system. The product is DIN rail mounted. Each of the four channels operates independently, allowing individualised control of the light intensity.

The dimmer complies with DALI protocol standards IEC 62386-102, IEC 62386-207 and is compatible with other international DALI products, ensuring interoperability in existing systems. The DALI address can be assigned manually and displayed on a digital display or can be assigned automatically by a DALI master. This dimmer uses pulse width modulation (PWM) for digital dimming and follows the standard DALI logarithmic dimming curve.

In addition to its controllability, the dimmer features overheating, overload and short-circuit protection and is capable of automatic recovery. It also has a quick self-test function to ensure reliable operation.
