Single-Phase Hybrid Solar Inverter SAJ H1 48V Pylontech Battery Charger Grid Injection 3.6-6 kW

The SAJ H1 Hybrid Inverter is a small, hybrid, transformerless, grid-connected inverter that synchronises itself with the electricity company's electricity grid to supply the energy produced in real time by the solar panels to our consumption. SAJ's H1 series can also be connected to 48V batteries such as PYLONTECH batteries.

This inverter can work with or without batteries and its main function is to transform the direct current from the panels into alternating current. The inverter together with the energy meter that is supplied separately allows to charge a battery with the surplus of the photovoltaic production and in this way to have energy available when the sun is not enough in order not to use energy from the electrical grid and to be as self-sufficient as possible.

SAJ's H1 hybrid range offers a very interesting access range to have a small self-consumption installation for private and residential use. In addition to its extremely attractive quality-price ratio, we add performance and production characteristics that are perfect for small and medium power.

Features of the SAJ Hybrid Single-Phase Inverter with On-Grid Battery Charger H1 3 to 6 kW

It has 2 internal MPPT regulators which, given the power of the inverter, are suitable for connecting panels in two strings. A wide range of operating voltage that will allow us to make series with greater comfort and flexibility. The MPPTs work between 90 and 550VDC.

The inverter has a power reduction control to avoid dumping excess production to the grid through a compatible wattmeter (sold separately) or storage in 48V batteries. It has a very good connectivity thanks to the integrated Wifi and RS232 communication, with App for IOS and Android to be monitored at all times. Its interface is simple and visual to be able to control its operation or any type of error.

H1 inverters can be installed indoors and outdoors thanks to its IP65 protection level and do not incorporate fans, so they are quieter than other inverters on the market.
