Power 60 W
Tension 220-240V AC
Luminosity 9000 lm
Number of LEDs 24
Power
60 W
Tension
220-240V AC
Luminosity
9000 lm
Number of LEDs
24
Type of dimming
1-10 V
Power Factor
0.95
IP protection
IP66
Width
766 mm
Height
440 mm
IK protection
IK09
Luminous Efficiency
150 lm/W
Material
Aluminium, Glass
60W LED Street Light 1-10V Dimmable LUMILEDS PHILIPS Xitanium Villa
Ref. Ledkia: 70521
Colour Temperature :
Neutral White 4000K
Optic :
Asymmetrical 140ºx60º
In stock, estimated delivery 9 to 10 days
£355.99
20% VAT included
In stock, estimated delivery 9 to 10 days
Are you a lighting professional or a company?
- Great discounts on RRP
- Extended warranty
- Exclusive services
Buy now, pay later
Credit payment30 Day Return
You can renounce to this product during the first 30 calendar days from receipt, provided that the product remains in perfect condition for use.
Custom-made products and cut-to-size strips are excluded.
Full conditions here: After-sales service.
24h Free Delivery
If you place your order today before 16:30h, delivery within 24/48h (working days).
Shipping is free on purchases over £ 49.99 (incl. VAT).
Full conditions here: Delivery methods.
100% secure payments
At Ledkia we strive to protect your security and privacy. We use payment methods that guarantee your security. Both your personal and bank details are protected with all the security measures established in the current legislation.
More information: Payment methods.
Up to 5 year warranty
Our warranty service of up to 5 years guarantees the replacement, repair or refund of defective products.
You will find the exact product warranty in the technical details.
Full conditions here: After-sales service.
Dimensions
- Height440 mm
- Width766 mm
- Weight10.2 kg
Downloads
Technical Data Sheet PDF
Certificates and Stamps
Energy Efficiency
Regulation 2023Technical Specifications
- Light colourNeutral White
- Colour Temperature4000K
- Energy efficiency 2023 (EU-2019/2015)D
- OpticAsymmetrical 140ºx60º
- Replaceable light sourceYes
- Available ComponentsYes
- Replaceable driverYes
- Power60 W
- Power Factor0.95
- Tension220-240V AC
- Nominal Voltage100-240V AC
- Overvoltage Protection6 kV
- Frequency50-60 Hz
- electrical insulation classI
- Light SourceLUMILEDS SMD5050
- Number of LEDs24
- Luminosity9000 lm
- Luminous Efficiency150 lm/W
- LED performance160 lm/W
- UseOutdoor
- IP protectionIP66
- IK protectionIK09
- ULORLess than 0.1%
- MaterialGlass, Aluminium
- Height440 mm
- Width766 mm
- Weight10.2 kg
- Ambient Working Temperature-20 °C~+45 °C
- Lifespan100.000 hours
- CertificatesRoHS, CE, ENEC
- Warranty5 years
- Type of dimming1-10 V
- Driver brandPHILIPS Xitanium
Description
The 60W LED Street Light 1-10V Dimmable LUMILEDS PHILIPS Xitanium Villa is one of the latest generation of luminaires, offering instantaneous ignition thanks to its LED technology, as well as great power. It is the ideal replacement for the old discharge lamps, improving the quality of light and significantly reducing energy consumption.
Characteristics of the 60W LED Street Light 1-10V Dimmable LUMILEDS PHILIPS Xitanium Villa
Built into the LUXEON 5050 2D light source. The light source is protected with tempered glass with an IP66 protection factor that makes it weatherproof. Lumileds technology guarantees high light output with extreme durability. Lumileds is a company dedicated to the development, manufacture and distribution of lighting and also holds over 200 patents related to LED technology.
The body of the luminaire has been manufactured using the injection method to guarantee the optimum quality of the heatsink, in high quality aluminium. It has an interior hinge that improves its aesthetics without losing its versatility. It has been treated with a chemical and mechanical anti-corrosion treatment that is resistant to UV rays, which further improves its aesthetic durability. In addition, for greater safety the luminaire has a surge protector.
Characteristics of the XITANIUM Dimmable 1-10V Driver
A LED driver transforms the alternating current from the mains into direct current suitable for shining the LED chips. The Xitanium Driver that it incorporates is from the prestigious company PHILIP, one of the most innovative and prestigious brands in the lighting industry. This driver is specially designed for Public Lighting. This range of drivers offers a unique reliability and flexibility, providing a high performance and optimum efficiency of LEDs. The entire range of Xitanium drivers incorporates an IP65 housing that protects against humidity, vibrations and temperature, guaranteeing maximum durability. In addition, it includes both over-temperature and surge protection.
This version is capable of regulating the luminaire by means of 1-10V regulation, i.e. the voltage of an alternate circuit is modified to regulate the intensity of light in the luminaire.
Reducing energy consumption means significant savings for any urban area. Enjoy the best street lighting with the different options of our Villa Luminaire on your online store Ledkia.
* The colour code of the luminaire is RAL 9011.
* To install the Villa LED Luminaire in some columns it is necessary to use the 'Villa LED Column Fixing Bracket' (see accessories).
