Wattage 14 W

Wattage
14 W
Voltage Range
220-240V AC
Power Factor
0.9
IP Rating
IP20
Dimensions
25 mm x 39.9 mm x 121.9 mm
Width
39.9 mm
Height
25 mm
Fitting Material
PC
Brand
LIFUD

Wattage : 14 W

14 W
In Stock, delivery in 24/48h

£8.89

VAT included

In Stock, delivery in 24/48h

Are you a lighting professional or a company?

Great discounts off PVP
Extended Warranty
Exclusive Services

See alternatives

Dimensions

Height25 mm
Depth121.9 mm
Dimensions25 mm x 39.9 mm x 121.9 mm
Width39.9 mm

Downloads

Technical Data Sheet PDF

Certificates and Stamps

Technical Specifications

Technical Information
- Temperature range in which the product can operate optimally, ensuring its performance without overheating or damage.
  Ambient Working Temperature-20 °C~+50 °C
- Quality, safety and compliance certifications that the product has obtained, such as CE, RoHS or UL, which guarantees that it meets industry standards and current regulations.
  CertificatesCE, TÜV, ENEC, UKCA
- Level of electrical current that the driver is capable of handling to power components, such as LEDs, ensuring safe and efficient operation.
  Driver Intensity200 mA-350 mA
- Voltage level that the driver uses to power the LEDs or electrical components of the product, guaranteeing their correct operation.
  Driver Tension25 V-42 V
- Level of electrical protection of the product against shocks. Indicates whether it is suitable for different conditions of use, guaranteeing safety in the installation.
  Electrical Insulation ClassII
- Composition of the product or its components, such as aluminum, steel, plastic or glass. The material influences the durability, design and thermal properties of the product.
  Fitting MaterialPC
- Range of cycles per second at which the product operates, measured in hertz (Hz). A standard value ensures compatibility with local electrical networks.
  Frequency50-60 Hz
- Level of protection against the entry of solids and liquids, according to international regulations. The two numbers indicate protection against dust (first number) and against water (second number).
  IP RatingIP20
- Indicates the electrical efficiency of the product by measuring the relationship between the useful power and that consumed. A value close to 1 represents more efficient consumption.
  Power Factor0.9
- Voltage level necessary for the product to function correctly. Ensures its compatibility with the electrical network or with specific power systems.
  Voltage Range220-240V AC
- Indicates how much energy the light source consumes, measured in watts (W). In LED lighting, the power is much lower than in traditional sources, and is related to the light intensity (lumens).
  Wattage14 W
Product Data
- Manufacturer or company responsible for designing and producing the product. A recognized name ensures quality and support.
  BrandLIFUD
- Period during which the customer has the right to have their product repaired or replaced in the event of manufacturing defects or malfunctions under normal conditions of use. For more information, consult our After-sales page.
  Warranty3 years

Description

The 220-240V LIFUD TRIAC Dimmable No Flicker Driver 25-42V Output 200-350mA 5-14W LF-ABT014-0350-42 is a professional solution from the renowned LIFUD brand, ideal for a wide range of lighting applications such as LED panels, LED downlights, LED panels and LED ceiling lights. This Driver is designed to connect directly to the Jack connector, facilitating installation and ensuring optimum compatibility. Its main function is to convert AC mains current into a DC current suitable for powering LED chips, ensuring that they operate efficiently and safely. To ensure compatibility with your lighting system, it is important to check the voltage and current output specifications of the driver.

Features of the 220-240V LIFUD TRIAC Dimmable No Flicker Driver 25-42V Output 200-350mA 5-14W LF-ABT014-0350-42

This specific Lifud model, the LF-ABT014-0350-42, excels in its ability to offer an adjustable multi-voltage output, ranging from 25V to 42V, allowing it to be used in different LED lighting configurations without compromising performance. This driver is designed to be Triac dimmable, allowing for effortless fine tuning of the light intensity. This dimming capability not only enhances the atmosphere of any space, but also contributes to the energy efficiency and longevity of your LED luminaires.

In addition, the output current can be adjusted from 200mA to 350mA via a DIP switch, providing exceptional flexibility. When the driver is switched on, it automatically adjusts the voltage required to maintain a constant and stable output, which is essential for the longevity and efficacy of the LEDs. With an outstanding power factor, this LED driver not only ensures quality illumination but also operates with superior energy efficiency, reflected in optimised power consumption and long-term cost savings.
