Barton 5W Aluminium Outdoor Solar LED Bollard with Motion Sensor 50cm

Technical Specifications

• Technical Information

  • Battery life of the luminaire at full charge, without wear, and at medium light level.
    Autonomy8 h
  • The amount of energy a battery can store, measured in mAh or Ah, indicating how long the device can operate before needing recharging.
    Battery Capacity2200 mAh
  • Specifies the voltage of the battery included in the product. This information is essential to guarantee compatibility with the product's electrical or charging system.
    Battery Voltage3.7 V
  • Quality, safety and compliance certifications that the product has obtained, such as CE, RoHS or UL, which guarantees that it meets industry standards and current regulations.
    CertificatesRoHS, CE
  • Time required to fully recharge the product's battery, depending on the battery capacity and the charging source.
    Charging Time6 h~8 h
  • Specification of the color of the product or its light (in the case of products such as lamps or light bulbs), which may affect the aesthetics and functionality of its use.
    ColourSilver
  • Defines the light tone, from warm white to cool white, measured in Kelvin (K).
    Colour Temperature3000K
  • Defines the sensitivity area of a sensor in degrees. A wider angle will detect motion over a larger area.
    Detection Range110 °
  • Maximum range at which a sensor can detect motion.
    Detention Range Metres10 m
  • It indicates that the product allows parameters such as light intensity, speed or color temperature to be adjusted, providing greater flexibility and customization.
    DimmableNo
  • Level of electrical protection of the product against shocks. Indicates whether it is suitable for different conditions of use, guaranteeing safety in the installation.
    Electrical Insulation ClassIII
  • Composition of the product or its components, such as aluminum, steel, plastic or glass. The material influences the durability, design and thermal properties of the product.
    Fitting MaterialAluminium
  • Estimated lifespan of the product before it loses performance. Based on optimal, non-continuous use, and measured in hours of operation under controlled conditions.
    Hours40.000 hours
  • Protection grade that the product offers against physical impacts. It is measured on a scale from IK00 to IK10, with IK10 being the highest level of resistance to impact and mechanical damage.
    IK ProtectionIK06
  • Information on how the product should be placed or mounted, such as instructions on whether it requires professional installation or is easy to do by the end user.
    InstallationSurface
  • The IP protection indicates the level of resistance of a product to dust and water. The higher the number, the more protected it is.
    IP RatingIP44
  • Characteristic that describes the tone of light emitted by the product, such as warm, neutral or cool. It is measured in degrees Kelvin (K) and affects the atmosphere and the proper use of space.
    Light ColourWarm White
  • Specification that describes the purpose or application of the product, such as lighting, air conditioning, or security, among others.
    LocationOutdoor
  • Total amount of light emitted by the product, measured in lumens (lm). A high value ensures well-lit spaces.
    Lumens510 lm
  • Ratio between light output (lumens) and energy consumed (watts). A high value indicates better efficiency, ideal for saving energy without compromising lighting.
    Luminous Efficiency100 lm/W
  • Number of locations where a light source can be installed or used. It is key to planning the distribution and intensity of lighting in a space.
    No. Of Lights1
  • Total number of light-emitting diodes (LEDs) in the product. The greater the number of LEDs, the generally obtained is greater luminosity or better light distribution.
    Number of LEDs60
  • Component that identifies changes in the environment, such as movement, light or sound, activating an automatic response, ideal for security or intelligent lighting systems.
    SensorRadar
  • Description of the type of sensor included in the product, such as a motion, light, temperature or presence sensor, which can activate or modify the operation of the product according to specific conditions.
    Sensor TypeRADAR Motion Sensor
  • Indicates how much energy the light source consumes, measured in watts (W). In LED lighting, the power is much lower than in traditional sources, and is related to the light intensity (lumens).
    Wattage4.4 W
  • Internal temperature range in which the product can operate efficiently and safely. It is important to ensure its reliability under different usage conditions.
    Working Temperature-5 °C~+40 °C

• Product Information

  • Element or component that emits light in the product, such as LEDs, incandescent or fluorescent bulbs. In LED systems, the light source is highly efficient and long-lasting.
    Light SourceSMD2835
  • Specifies the type of battery used in the product, such as lithium, lead-acid, or NiMH. Each type has different performance, durability and load characteristics.
    Type Of BatteryLi-ion
  • Method used to charge the product, such as fast, inductive, or standard charging. Depending on the type, charging time and efficiency may vary.
    Type Of ChargeSolar

• Product Data

  • Period during which the customer has the right to have their product repaired or replaced in the event of manufacturing defects or malfunctions under normal conditions of use. For more information, consult our After-sales page.
    Warranty3 years
