Power 18 W
Tension 220-240V AC
Luminosity 1400 lm
cut out dimensions 205 mm x 205 mm
Power
18 W
Tension
220-240V AC
Luminosity
1400 lm
cut out dimensions
205 mm x 205 mm
IP protection
IP20
Battery operated
No
dimensions
20 mm x 220 mm x 220 mm
Width
220 mm
Height
20 mm
IK protection
IK05
Luminous Efficiency
78 lm/W
Selectable Opening Angle
120º
18W Square SuperSlim LED Downlight with 205x205 mm Cut-Out
Ref. Ledkia: 222
(94)4.5 out of 5 stars
Colour Temperature :
Neutral White 4000K
Before 5,48 €
3,75 €
23% VAT included
In Stock, delivery in 15-20 days
Includes Driver
Are you a lighting professional or a company?
- Great discounts on RRP
- Extended warranty
- Exclusive services
Buy now, pay later
Credit payment30 Day Return
You can renounce to this product during the first 30 calendar days from receipt, provided that the product remains in perfect condition for use.
Custom-made products and cut-to-size strips are excluded.
Full conditions here: After-sales service.
5-7 days Free Delivery
If you place your order today before 18:00h, delivery within 5-7 days (working days).
Shipping is free on purchases over 49,99 € (incl. VAT).
Full conditions here: Delivery methods.
100% secure payments
At Ledkia we strive to protect your security and privacy. We use payment methods that guarantee your security. Both your personal and bank details are protected with all the security measures established in the current legislation.
More information: Payment methods.
Up to 5 year warranty
Our warranty service of up to 5 years guarantees the replacement, repair or refund of defective products.
You will find the exact product warranty in the technical details.
Full conditions here: After-sales service.
Dimensions
- Height20 mm
- Width220 mm
- dimensions20 mm x 220 mm x 220 mm
- cut out dimensions205 mm x 205 mm
- Length220 mm
Downloads
Technical Data Sheet PDF
Certificates and Stamps
Energy Efficiency
Regulation 2023Technical Specifications
- Light colourNeutral White
- Colour Temperature4000K
- Energy efficiency 2023 (EU-2019/2015)F
- Available ComponentsYes
- Replaceable driverYes
- Replaceable light sourceNo
- Power18 W
- Tension220-240V AC
- Nominal Voltage170-265V AC
- Frequency50-60 Hz
- electrical insulation classII
- DimmableNo
- Light SourceOSRAM
- Chromatic Reproduction Index80
- Luminosity1400 lm
- Luminous Efficiency78 lm/W
- Type of lensOpaal
- UseIndoor
- IP protectionIP20
- IK protectionIK05
- MaterialPC, Aluminium
- InstallationRecessed
- dimensions20 mm x 220 mm x 220 mm
- cut out dimensions205 mm x 205 mm
- Height20 mm
- Width220 mm
- Length220 mm
- Ambient Working Temperature-30 °C~+50 °C
- Battery operatedNo
- IncludesDriver
- Remote controlNo
- WiFiNo
- Lifespan40.000 hours
- CertificatesRoHS, CE, UKCA
- Includes sensorNo
- Contains batteryNo
- Cut out length205 mm
- Cut out width205 mm
- Driver tension30 V-38 V
- Operates with Emergency LightingNo
- FireproofNo
- Warranty3 years
- Driver intensity400 mA
- Selectable Opening Angle120º
Description
The 18W Square SuperSlim LED Downlight with 205x205 mm Cut-Out is extremely thin and has an innovative, modern design.
Features of the 18W Square SuperSlim LED Downlight with 205x205 mm Cut-Out
Its 2835 SMD LEDs offer a brightness of 1400lm, which is equivalent to 130W of halogen lighting. The light it emits is distributed at an angle of 120º which makes it perfect as a general lighting source. It works with a voltage of 220-240V AC, but is prepared to withstand variations between 85-265V AC.
The 18W Square SuperSlim LED Downlight with 205x205 mm Cut-Out has an aluminium dissipater included which contributes to the minimum heat emission from this LED downlight. Furthermore, being so thin, it can be installed in false ceilings even where larger luminaires could not be used.
The LED Panels at our online LED lighting shop have a life span of 30,000 hours. Sign up now for energy efficiency with Ledkia.
