Voltage Range 24V DC
Type Of Dimming DALI
IP Rating IP20
Dimensions 50 mm x 112 mm x 112 mm

1 / 4

Voltage Range
24V DC
Type Of Dimming
DALI
IP Rating
IP20
Dimensions
50 mm x 112 mm x 112 mm
Width
112 mm
Height
50 mm
Fitting Material
Glass, PC
Dimmable
Yes
Working Temperature
-20 °C~+55 °C

Light Colour : RGB

RGB

In Stock, delivery in 15-20 days

34,29 €

VAT included

In Stock, delivery in 15-20 days

Are you a lighting professional or a company?

Great discounts off PVP
Extended Warranty
Exclusive Services

See alternatives

Dimensions

Height50 mm
Depth112 mm
Dimensions50 mm x 112 mm x 112 mm
Width112 mm

Downloads

Technical Data Sheet PDF
IM_115057_115061_115066_115070

Certificates and Stamps

Technical Specifications

Technical Information
- Temperature range in which the product can operate optimally, ensuring its performance without overheating or damage.
  Ambient Working Temperature-30 °C~+65 °C
- Quality, safety and compliance certifications that the product has obtained, such as CE, RoHS or UL, which guarantees that it meets industry standards and current regulations.
  CertificatesDALI 2, RED, RoHS, CE, EMC
- Specification of the color of the product or its light (in the case of products such as lamps or light bulbs), which may affect the aesthetics and functionality of its use.
  ColourWhite
- It indicates that the product allows parameters such as light intensity, speed or color temperature to be adjusted, providing greater flexibility and customization.
  DimmableYes
- Composition of the product or its components, such as aluminum, steel, plastic or glass. The material influences the durability, design and thermal properties of the product.
  Fitting MaterialGlass, PC
- Information on how the product should be placed or mounted, such as instructions on whether it requires professional installation or is easy to do by the end user.
  InstallationRecessed
- Level of protection against the entry of solids and liquids, according to international regulations. The two numbers indicate protection against dust (first number) and against water (second number).
  IP RatingIP20
- Characteristic that describes the tone of light emitted by the product, such as warm, neutral or cool. It is measured in degrees Kelvin (K) and affects the atmosphere and the proper use of space.
  Light ColourRGB
- Specification that describes the purpose or application of the product, such as lighting, air conditioning, or security, among others.
  LocationIndoor
- Voltage level necessary for the product to function correctly. Ensures its compatibility with the electrical network or with specific power systems.
  Voltage Range24V DC
- Internal temperature range in which the product can operate efficiently and safely. It is important to ensure its reliability in different conditions of use.
  Working Temperature-20 °C~+55 °C
Product Data
- Period during which the customer has the right to have their product repaired or replaced in the event of manufacturing defects or malfunctions under normal conditions of use. For more information, consult our After-sales page.
  Warranty5 years
Product Information
- System used to control product characteristics, such as intensity regulation, color temperature or speed, adjusting its performance according to the user's needs.
  Type Of DimmingDALI

Description

The 4 Zone Tactile Wall Mounted DALI RGB Master Dimmer is a touch RGB regulator that acts as a DALI master to control a DALI address. It uses proximity detection technology to provide intuitive and effective control. Its elegant design integrates perfectly into professional DALI lighting systems. As it is an RGB regulator, we can control the light intensity and switch between many colours thanks to the DT8 standard.

Features of the 4 Zone Tactile Wall Mounted DALI RGB Master Dimmer

It complies with the latest DALI standard protocol IEC62386 and is compatible with DALI products from other international incorporations. This touch panel is powered through the DALI bus or a 24VDC source, making it versatile and easy to integrate into different installations.

This DALI Master offers control over the lighting in four different zones. This means it can handle and adjust the lighting in four separate areas independently, allowing for extreme customisation of the environment according to needs or specific events. Each zone can be configured with different colours, intensities, and effects, providing flexibility and creativity in lighting design. This level of zoned control is ideal for spaces that require multiple lighting environments or to enhance unique architectural features in each area.

A standout feature of this panel is its ability to select the DALI address using an encoding switch. It also allows for complete customisation of lighting control, including scenes, groups, and linking or fading modes. The touch panel is designed with an ultra-sensitive, highly resistant glass surface that is not only elegant but also durable. Each button is equipped with a blue LED indicator, making it easy to identify the buttons in low-light conditions.
