Wattage 11000 W

1 / 4

Wattage
11000 W
Voltage Range
400V AC
Max Wattage
22 kW
IP Rating
IP55
Dimensions
310 mm x 83.5 mm x 161 mm
Width
83.5 mm
Height
310 mm
Connectivity
Wi-Fi
App
Tuya Smart
Fitting Material
PC
Current Intensity
13 A

Wattage : 11000 W

11000 W
Pre-Order, estimated shipping from 14/06/2025
22000 W
Pre-Order, estimated shipping from 18/06/2025

525,54 €

VAT included

Pre-Order, estimated shipping from 14/06/2025

Are you a lighting professional or a company?

Great discounts off PVP
Extended Warranty
Exclusive Services

See alternatives

Dimensions

Height310 mm
Depth161 mm
Dimensions310 mm x 83.5 mm x 161 mm
Width83.5 mm

Downloads

Technical Data Sheet PDF
manual2024_12_13

Certificates and Stamps

Technical Specifications

Technical Information
- Temperature range in which the product can operate optimally, ensuring its performance without overheating or damage.
  Ambient Working Temperature-20 °C~+50 °C
- Quality, safety and compliance certifications that the product has obtained, such as CE, RoHS or UL, which guarantees that it meets industry standards and current regulations.
  CertificatesRoHS, CE, UKCA
- Amount of electrical current that flows through the product, measured in amperes (A). It is key to ensuring safe and efficient operation.
  Current Intensity13 A
- Level of electrical protection of the product against shocks. Indicates whether it is suitable for different conditions of use, guaranteeing safety in the installation.
  Electrical Insulation ClassI
- Composition of the product or its components, such as aluminum, steel, plastic or glass. The material influences the durability, design and thermal properties of the product.
  Fitting MaterialPC
- Range of cycles per second at which the product operates, measured in hertz (Hz). A standard value ensures compatibility with local electrical networks.
  Frequency50-60 Hz
- Information on how the product should be placed or mounted, such as instructions on whether it requires professional installation or is easy to do by the end user.
  InstallationSurface
- Level of protection against the entry of solids and liquids, according to international regulations. The two numbers indicate protection against dust (first number) and against water (second number).
  IP RatingIP55
- Specification that describes the purpose or application of the product, such as lighting, air conditioning, or security, among others.
  LocationOutdoor, Indoor
- The maximum amount of power that the product can safely consume, indicated in watts. It is important to ensure proper installation and avoid overloading.
  Max Wattage22 kW
- Voltage level necessary for the product to function correctly. Ensures its compatibility with the electrical network or with specific power systems.
  Voltage Range400V AC
- Indicates how much energy the light source consumes, measured in watts (W). In LED lighting, the power is much lower than in traditional sources, and is related to the light intensity (lumens).
  Wattage11000 W
Product Data
- Period during which the customer has the right to have their product repaired or replaced in the event of manufacturing defects or malfunctions under normal conditions of use. For more information, consult our After-sales page.
  Warranty3 years
Product Information
- Mobile application compatible with the product, which allows you to control or configure it from your device in a simple and intuitive way.
  AppTuya Smart
- Technology or means that allows the product to connect to networks, devices or systems, such as Wi-Fi, Bluetooth or cables. Make it easy to control or integrate into your smart home.
  ConnectivityWi-Fi

Description

The 5m 11-22kW Three Phase SMART WiFi Electric Car Charger is a Three phase electric vehicle charger with a 5m cable hose with Type 2 connector. The charger can be operated directly, simply connect the charger to the electric vehicle and the charging process starts automatically. For those who need more control over the charging process, the charger also operates with a radio frequency identification (RFID) system. This mode requires an authorised RFID card or tag to activate charging. By presenting the RFID card to the charger, the user can start or stop charging, providing an additional layer of security and control. This is particularly useful in environments where multiple users may need to access the charger, such as in offices or flat communities, as it allows use to be restricted to only those with authorisation.

Thanks to its internet connectivity, this charger can be configured and controlled via the Tuya app, allowing you to monitor and manage the charging process from the palm of your hand, offering great convenience and control. You can regulate the intensity of the charge, therefore, its power, so that it does not exceed the contracted power, avoiding the tripping of the magneto-thermal protections that we have. It is also possible to program the switch-on time and the duration of the charge.

In the case of installing the charger in a community of neighbours, all interested parties should have an RFID card. The product includes 3 master RFID cards that can be duplicated with any RFID reader at a very low cost so that all the neighbours have their own. The card reader makes it easy to identify which users are using the charger and how much energy each of them has consumed.

Features of the 5m 11-22kW Three Phase SMART WiFi Electric Car Charger

Its design is modern and very focused on charging in private environments. It is installed on a wall or on posts specially designed for the chargers. It is made of PC-540 resin from PC+ABS of the highest quality, it also has an IP54 rating, allowing it to be installed outdoors. It is sun-resistant and waterproof and has an IK10 mechanical resistance factor to protect against vandalism.

Applications of the 5m 11-22kW Three Phase SMART WiFi Electric Car Charger

This charger is specially designed for smart charging of electric vehicles in private, hotels, companies, residential communities...etc.

* Complies with IEC 61851-1:2017-02 IEC 62053-21:2003,EN 50065-1:2001, EN 50557:2011, IEC 60050-151:2001, IEC 60050-195:1998, IEC 60050-441:1984,IEC 60050-826:2004 and IEC 62196-2:2011-10.
