Range Essential

Power 18 W
Tension 220-240V AC
Luminosity 1480 lm
Diameter 225 mm

1 / 7

Power
18 W
Tension
220-240V AC
Luminosity
1480 lm
Diameter
225 mm
IP protection
IP20
dimensions
32 mm x Ø225 mm
Height
32 mm
Luminous Efficiency
82 lm/W
Selectable Opening Angle
120º
Material
PC, Aluminium
Chromatic Reproduction Index
80
Dimmable
No

Colour Temperature :

Warm White 3000K

In Stock, delivery in 15-20 days

Neutral White 4000K

In Stock, delivery in 15-20 days

Cool White 6000K

In Stock, delivery in 15-20 days

10,66 €

23% VAT included

In Stock, delivery in 15-20 days

Includes Driver

Are you a lighting professional or a company?

Great discounts on RRP
Extended warranty
Exclusive services

Further information

Buy now, pay later

Credit payment

30 Day Return
You can renounce to this product during the first 30 calendar days from receipt, provided that the product remains in perfect condition for use.

Custom-made products and cut-to-size strips are excluded.

Full conditions here: After-sales service.
5-7 days Free Delivery
If you place your order today before 18:00h, delivery within 5-7 days (working days).

Shipping is free on purchases over 49,99 € (incl. VAT).

Full conditions here: Delivery methods.
100% secure payments
At Ledkia we strive to protect your security and privacy. We use payment methods that guarantee your security. Both your personal and bank details are protected with all the security measures established in the current legislation.

More information: Payment methods.
Up to 5 year warranty
Our warranty service of up to 5 years guarantees the replacement, repair or refund of defective products.

You will find the exact product warranty in the technical details.

Full conditions here: After-sales service.

Dimensions

Height32 mm
Diameter225 mm
dimensions32 mm x Ø225 mm

Downloads

Technical Data Sheet PDF

Certificates and Stamps

Energy Efficiency

Regulation 2023

Technical Specifications

Light colourWarm White
Colour Temperature3000K
Energy efficiency 2023 (EU-2019/2015)F
Replaceable driverYes
Replaceable light sourceNo
Available ComponentsYes
Power18 W
Tension220-240V AC
Nominal Voltage170-265V AC
Frequency50-60 Hz
electrical insulation classII
DimmableNo
Light SourceOSRAM
Chromatic Reproduction Index80
Luminosity1480 lm
Luminous Efficiency82 lm/W
Type of lensOpaal
UseIndoor
IP protectionIP20
MaterialAluminium, PC
InstallationSurface
dimensions32 mm x Ø225 mm
Height32 mm
Diameter225 mm
Ambient Working Temperature-40 °C~+50 °C
IncludesDriver
Lifespan40.000 hours
CertificatesRoHS, CE, UKCA
Warranty3 years
Driver intensity390 mA
Driver tension30 V-38 V
Selectable Opening Angle120º

Description

This Round 18W LED Surface Panel Ø225 mm is easy to install and perfectly complies as a main lighting element in any space.

Featuring a highly efficient light source that produces 1,480 lumens. This brightness allows us to save a considerable amount, including when compared with fluorescent surface panels. Also, with a 30,000 hour working life, it lasts much longer that a conventional luminaire, which is an important factor when it comes to saving.

Uses for this Round 18W LED Surface Panel Ø225 mm

This type of lighting is used in indoor spaces. Its wide 120º opening angle allows light to be distributed homogeneously and the frosted diffuser it incorporates eliminates any potential glare that might be produced.
